Ford F-150 (2021 - 2023) - fuse box diagram. Year of production: 2021, 2022, 2023. Under Hood Fuse Box version 1. Fuse location: Fuse rating: Protected component: 1: 40A: Body control module - battery power in feed 1: 3: 40A: Body control module - battery power in feed 2: 4: 30A: Fuel pump: 5: 5A: Keep-alive power. 1 Under Hood Fuse Box Location. 2 Under Hood Fuse Box Diagram. 3 Body Control Module Fuse Box Location. 4 Body Control Module Fuse Diagram. 5 2021 Ford F-150 Owners Manual. Below are all the fuse diagrams for the 2021 Ford F-150. Both passenger and engine fuse boxes are covered, showing all relays and fuses.
